Product Usage

Suitable for anodic and cathodic electrophoretic coating shell car, motorcycle frames, glasses accessories, household hardware accessories, handicrafts and other metal materials.

Features

The new circuit, new design, new style; highly reliable control system with anti-interference ability, high control accuracy, good stability, reliable operation; using high-performance filter, effectively inhibited the rectified output voltage harmonics wave component, low ripple output must meet the requirements of electrophoretic coating production process; with 0 to 999 seconds adjustable soft-start function, current, voltage, and can be set according to the technical requirements of the regulator or the steady flow mode selection; use multi-voltage rise control devices, each operating voltage and is free to set the preset time, the setting is finished, you can work according to the data set, the task is completed after a single voltage auto-zero, concurrent sound and light alarm, automatic stop working then just press the reset button, the machine will be set according to the original data back to work until it is completed; over-current, over voltage, short circuit, phase, overheating protection function; with this remote control with dual controls, easy to use .

Product Specifications
Output DC current: 10 ~ 15000A optional
DC output voltage: 50 ~ 350V optional
Specifications and Dimensions
