- Size: 00x00
- Place of Origin: Qingdao,China
- Brand Name: Lanyu
- Model Number: KGCA
- Weight: 10.000 kg
Outline
For small sealed batteries into the battery pack and the charging and discharging, 3000SH type for low harmonic environmental models.
Feature
The product is based on SCR (SCR) all-digital control technology, the system is stable and reliable power supply by a microcomputer control all the way, pour the modular structure, attractive appearance. Easy to operate, powerful, high accuracy, high reliability, low noise, discharge feedback network, and have self-diagnostic, the user can handle the fault information and so on. 6A following specifications using patented technology, no quick fuse, greatly facilitate the users. SH type which is environmentally friendly low harmonic.
Function
You can set all kinds of batteries into the program and the process parameters, with constant current charging, constant voltage charging, constant current limiting charging, constant pressure limiting discharge cycle, standing and other work, has given time, constant voltage, constant Ah the phase conversion mode and timer record function operating data; overcurrent, overvoltage, stop, and power-down data retention, calls automatic recovery functions; a battery anti-reverse, over discharge, output short circuit ignition protection, power outage protection and other protection, LED display the current running through the data and the reasons for failure, communication interface with the PC connected via multiple power supplies can achieve centralized network control and data processing.
Technical Specifications
1, the current control range: 1 ~ 100% FS
2, the voltage control range: 10 ~ 100% FS
3, steady flow regulation accuracy: ≤0.5% FS
4, the time accuracy: ≤15s / 24h
5, the current harmonic content: 3000S: <30% 3000SH: <10%
Size
Model Specifications | Output CurrentA | The output voltageV | Each loop | Dimensions | Weight Approx (kg) | ||
Width w | High h | Deep d | |||||
KGCA-3A/320V | 3 | 320 | 24 30 40 | 100 | 200 | 80 | 400-500 |
KGCA-5A/320V | 5 | 320 | 24 30 40 | 100 | 200 | 80 | 400-500 |
KGCA-6A/320V | 6 | 320 | 24 30 40 | 100 | 200 | 80 | 450-550 |
KGCA-8A/320V | 8 | 320 | 12 15 24 30 | 120 | 200 | 80 | 600-750 |
KGCA-10A/320V | 10 | 320 | 12 15 24 30 | 120 | 200 | 80 | 700-850 |
KGCA-12A/320V | 12 | 320 | 12 15 | 120 | 200 | 80 | 720-800 |
KGCA-15A/320V | 15 | 320 | 12 15 | 120 | 200 | 80 | 750-800 |
